Everlast CYCLONE 312 315amp MIG STICK Welder 220v / 240v
Everlast CYCLONE 312 315amp MIG STICK Welder 220v / 240v
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Multi-Process | Yes |
| Model | Cyclone 312 |
| MPN | NOT SPECIFIED |
| Voltage | 240 V |
| Features | With Gas |
| Welded Material | Stainless Steel |
| Welding Process | MIG |
| Item Type | MIG Welder |
| Brand | Everlast |
Power i-TIG 200T About UsContact UsShop PoliciesFAQFeedback SKU: CYCLONE 312 Product Description The Cyclone 312 simply delivers beast mode performance. As one of our newest generation inverter MIG/Stick welders, offering up to 315A MIG output and 250A Stick output with 35% duty cycle at maximum output the Cyclone 312 outdelivers similar competitor models on both maximum output and duty cycle. Even though it's the most powerful in it's class, the inverter design also makes it among the smallest and lightest in its class for a self-contained, trolley type (self contained undercarriage) welder. It's definitely smaller and lighter than it's transformer based competitors. The new digital user interface of the machine features a 4.3" TFT LCD display. This display offers full contrasting color with bright and large numerical readouts so that settings can be easily read, even from far away. This new design incorporates many extra features which include pre and post gas flow control, inductance (arc force), and burn back control to improve weld quality and performance. Of course, keeping true to its industrial design it also features functions like 2T and 4T control for long seam welding. For the applications where body work, building vessels, or hanging large panels and sheets are required the unit features spot and stitch timers which work together to provide consistent and high quality spot welds and seam sizes. One of the new features include a professional level "Power Set" mode which allows all users, new or advanced, rapid, no-guess setup. The user simply provides operating parameters such as gas, wire type and size and the machine will provide the user with the correct Volts and Wire Speed with an adjustable range that can be fine tuned for specific applications such as position, or welding thick to thin. And if you create your own special programs, this machine features a memory function that can save multiple programs in both MIG and Stick modes.For those needing aluminum work, the unit will work well with the Parker DSP 360 spool gun and offer premimum quality aluminum MIG welds, or for bulk aluminum use, the operator can choose to use the optional polymer liner with the stock 36 series MIG gun and optional U-groove aluminum drive rolls to drive the aluminum through the gun. Not many MIG guns have this feature, but when you need to lay down a lot of aluminum, it's nice not to be constricted by a bulky spool gun.As a stick welder, the machine is highly capable, providing up to 250A output which allows use with cellulose type rods such as E6010 and in powerset mode, it offers specialized settings for many different steel rods. PRODUCT EXTRAS Features & Benefits: Heavy Duty Commercial Construction Large 4.3" TFT LCD Display with high contrast appearancePowerSet function quickly dials in proper settings to give all users a fast, easy setup experienceMemory function allows multiple programs to be saved by user Highly capable E6010 setting along with other rod type selections for improved performanceUndercarriage with cylinder rack built inPowerSet Function for easy setup for pros and beginnersCommercial MIG Duty Cycle @ 35% @ 315A and 60% @ 250ACommercial Stick Duty Cycle @ 35% @ 250A and 60% @ 200A240V single phase operationHolds 12" roll, may use optional 8" spool adapterSpot and Stitch Timer for Seam weldingBurn Back control for reduced wire trimmingRun-In FeatureGas Purge and Wire JogInductance/Arc Force Control for dialing in puddle fluidity and aggressiveness of the MIG/Stick arc.Adjustable Pre/Post Flow.Start and End Wire feed speedsSpool gun capability4 Roll Gear Driven Wire Feeder (All four rollers are gear driven)NEMA 6-50 Plug WHAT'S INCLUDED Standard Equipment: 36 Series MIG Gun with 10 ft. cableWork Clamp with 10 ft. cable and 35 series DINSE type AdapterAr/CO2 regulatorElectrode Holder (Stick) with 10 ft. cable and 35 DINSE type AdapterDrive Roll V Groove .035"-.045" (Double) OPTION Optional Equipment: Parker DSP 360 Spool GunAdditional Drive Rolls for Flux-Core and Alternate Sizes36 Series MIG Gun with 15 ft. cableRECOMMENDED USES Recommended Areas of Use: FabricationProduction and Assembly LinesFarm/RanchMotor SportsStructuralRecommended Metals: SteelChrome MolyStainlessAluminum (With optional Parker Spool Gun) TECH SPECS Type: Digital/Micro-controlled IGBT InverterOutput /Process Type: MIG, StickVoltage/phase: 220/240 V 1 PHASEMax Rated MIG Amps: 315AMax Rated Stick Amps: 250AMIG Amps/Volts @ Rated Duty Cycle: 315A/29.8V @ 35% Duty Cycle @ 40° C250A/26.5V @ 60% Duty Cycle @ 40° C200A/24V @ 100% Duty Cycle @ 40° CStick Amps/Volts @ Rated Duty Cycle: 250A/30V @ 35% Duty Cycle @ 40° C200A/28V @ 60% Duty Cycle @ 40° C160A/26.4V @ 100% Duty Cycle @ 40° CMax Inrush ( I1MAX ) Amps: 64AMaximum Rated (I1EFF ) Input Amps: 38AOCV: 70VMIG Output Range: 30- 315A /15.5- 29.8VStick Output Range: 10-250A / 20.4-30VVariable MIG Inductance/Stick Arc Force Control: YesSpool Gun Capable: YesPulse: NoStandard Drive Roll wire size: .035”-.045”Separate wire feeder: No, self containedNumber of Drive rollers: 4Max Wire Feed Speed: 700 IPMMax Wire Roll Diameter: 12” (full size up to 44lb)Memory: YesPreflow time: AdjustablePost Flow Time: AdjustableFlux Core: Yes, OptionalAir Carbon Arc: No2T/4T /Torch latch/Trigger: YesTorch Type: MB 36 seriesOther Features: Burn Back Time: 0-2.0 SecondsArc Force/Inductance: 0-100%Spot TimerStitch TimerStart Wire SpeedEnd Wire SpeedUpSlope Wire Feed TimeDownSlope Wire Feed TimeE6010 Stick capability NOTES: Product Notes: This unit is intended for Commercial/Industrial/Agricultural use, with facilities wired for commercial single phase 240V use. However, before installing this unit in any facility, consult a licensed electrician, and refer to Article 630 in the NEC for proper wiring instructions for welders. Use the Maximum Inrush and the Effective rated current for breaker and wiring sizing (respectively). If using for residential, or home shop use, make sure the wiring codes are followed and proper breaker sizes are installed. If this unit is to be used with a generator, the generator MUST be rated for 5% or less THD (Total Harmonic Distortion), which is typically regarded as the maximum threshold for clean power rated generators. In addition, the total surge wattage rating must be 16000 watts or greater. Use with undersized generators, or with generators not rated by the generator's manufacturer as "5% or less THD" is prohibited and will void the warranty. This unit is not intended for arc gouging or cutting. Such use may damage the machine and void the warranty. MINIMUM/MAXIMUM Minimum/Maximum: Steel/Stainless: 24-22 Gauge to 1/2" Single PassSteel/Stainless up to 1 1/4" multi-pass or greater.Aluminum: 18 Gauge to 3/8" Single PassAluminum up to 1" or greater Multi-Pass or greaterNote: Steel/Stainless Single Pass figure is based off of Axial Spray transfer mode. All Aluminum should be done in Axial Spray only. Single/Multi- pass recommendations are not necessarily recommended or accepted as best industry practice and intended for use with properly prepped and beveled joints.Optional Drive rolls may be required to achieve minimum or maximum specifications.. Returns For returns, contact must be made within72 hours of delivery so an RMA number is issued. If there is damage, we can help file a damage claim immediately. DOA items: In the event you receive a non working unit , we will exchange it free of charge. Items returned must be in an GOOD condition. We will inspect all returns before accepting the package. We will not accept packages that have missing parts, damages, and packages that have not been approved for return by our initial contact or packages missing an RMA number. These packages will be refused and sent back to YOU at your cost. Shipping Information: 1- We have an onsite professional shipping and packaging department and adhere to all shipping guidelines. 2- We will try to ship orders as soon as possible after payment approval unless otherwise stated in description. NOTE: Since there are many ways we offer our products, on rare occasions there is a chance an item may go out of stock that we have listed and sold on eBay. We will do our best to expedite backordered items as soon as possible. 3- Please provide a physical address. We will not ship to a PO Box. 4- Shipping charges are for the (48) Continental United States only. 5- We don’t ship to Canada 6- We charge CA tax on all orders 9.5% 7- If you pay via PayPal, shipping will be to your confirmed address only 8- Shipping to AK, HI and PR is more. please email for price. Contact Operating Hours: Monday through Friday: 9AM to 5PM PSTSaturday: 11AM to 4PM (PST)
