Eastwood Versa Cut 60 Amp Metal Cutting Plasma Cutter Improved with 2T/4T and…
Eastwood Versa Cut 60 Amp Metal Cutting Plasma Cutter Improved with 2T/4T and…
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Eastwood |
| MPN | 58221 |
| Item Type | Plasma Cutter |
Quickly and precisely carve all types of metal as well as body panels and more with this heavy-duty Eastwood plasma cutter. The Eastwood Versa-Cut 60 is our most powerful metal-cutting solution. The adjustable 60-amp output and Trafimet CB70 torch can cut through metal ranging from 24-gauge sheet metal to thick 7/8 inch plates. Use it on mild steel, stainless and aluminum in your shop or at a worksite. At only 31 pounds, this lightweight portable plasma cutter works fast and allows you to cut intricate curves and angles with little slag to remove. Backed by Eastwood's no-hassle 3-year warranty 120 or 240 Volts AC input Cuts thin sheet metal to thick 7/8" thick plate (cuts 3/16" on 120 VAC) Digital amperage readout for increased precision Long 20' torch cable and 10' ground cable with clamp Rated 60 amp output on 240 VAC; 30 amp on 120 VAC Lightweight and Portable - only 31 lbs! 2T/4T Torch Mode for smoother long cuts Durable Duty Cycle of 60% @ 60 amps on 240v and 60% @ 30 amps on 120v Uses common consumables that are available at Eastwood or most welding supply stores Specifications Input: 240 VAC and 120 VAC, 50/60 Hz, 1 Ph Rated Input Current 120 VAC: 39.4 Amps Rated Input Current 240 VAC: 44.5 Amps Output Current Adjustment 120 VAC: 20 - 30 Amps Output Current Adjustment 240 VAC: 20 - 60 Amps Amps Output Voltage on 120 VAC: 88V - 92V Output Voltage on 240 VAC: 88V - 104V Power Cord Receptacle Plug: NEMA 6-50P Power Cord Length: 6' Output: 60 Amps Duty Cycle: on 120 VAC:60% @ 30 Amps and 100% @ 23 Amps Duty Cycle: on 240 VAC:60% @ 60 Amps and 100% @ 46 Amps Torch: Trafimet CB70 Torch Tip: 0.1mm Max Cut: 7/8" on 240 VAC; 3/16" on 120 VAC Air Compressor Requirements: 5-7 cfm @ 20 - 60 psi Torch Cable Length: 20' Ground Cable Length and Gauge: 10' long, 5 gauge wire Cooling Method:Fan Air Connection Thread: 1/4" NPT Unit Dimensions: 17.01" Long X 14.69" Tall X 8.46" Wide Unit Weight: 31 lbs Contents (1) Versa-Cut 60 Amp Plasma Cutter (1) Trafimet CB70 Torch and 20’ Supply Line (1) 10’ Ground Lead and Clamp (1) NEMA5-15P to NEMA 6-50R, 2' (240v to 120v Cable) (1) Torch Flow Tester (1) Electrode Wrench (1) Replacement Electrode (1) Replacement Nozzle (1) Instruction Manual WARNING - California Proposition 65 - www.P65Warnings.ca.gov
